Description
Parameter
Labeling Error | ±0.5mm |
Labeling Speed | 15-30pcs/min |
Suitable Bottle Size | H 20mm-200mm W 20mm-150mm |
Suitable Label Size | L 20mm-100mm W 15mm-150mm |
Power Supply | 220V/50Hz |
Machine Size | 860x430x790mm |
Machine Weight | 49kg |
Label Inner Diameter | 76mm |
Label Outer Diameter | ≤300mm |
Application
Labeling is carried out by means of suction and sticking to achieve labeling on the plane of various work pieces, such as cosmetic flat bottles, packaging boxes, plastic cover labeling, etc.
Change the labeling mechanism, which can be applied to uneven surface labeling, such as labeling of concave planes and circular planes.
Notice
1.Optional matching ribbon printer and jet printer, labeling at the same time print production batch number, production date, expiration date and other information, labeling, one-step completion of coding, greatly improving production efficiency.
2.It need to custom the fixture to apply to the labeling of various irregular work pieces.(please send you bottle or measure your bottle size )
3.We can custom the machine to apply your label and bottle . please contact with us
