Description
特 点 Characteristic
1、适用于食品、医药、化工、化妆品行业中颗粒、粉剂、液体、酱料等物品的计量包装。
It is suitable for the measurement and packaging of granules, powders, liquids, sauces and other items in the food industry.
2、调试方便，占用空间小。包装流程全自动，无需人工操作。可根据充填物料的性质选配不同的下料结构。
Convenient debugging, small space. The packaging process is fully automatic without manual operation. Different feeding structures can be selected according to the nature of filling materials
3、采用触摸屏操作，PLC控制，封口温度自动补偿，控温精准，封口美观大方。
It adopts touch screen operation, PLC control, automatic compensation of sealing temperature, precise temperature control, and beautiful sealing.
4、包装材料：PE复合膜，如：纯铝，镀铝等预制袋。
Packing material: PE composite film, such as: pure aluminum, aluminum plating and other prefabricated bags.
封口方式 Sealing Type
预制袋Prefab bag
技术参数Technical Parameters
计量范围：200-1000g
Measuring Scope
预制袋（最大）：长 ( L ) ：280mm
Preformed bag(Max) 宽 ( W ) ：200mm
包装速度：15 - 25bags / min
Packing Speed
外型尺寸：1091 * 926 * 1990 mm
Dimension ( L * W * H )
整机重量：370 kg
Weight
总 功 率：AC220V / 50 - 60Hz / 2.2kw
Total Power
