Description
Feature
1.The filling speed of four heads can be controlled separately. Easy to operate.
2.The machine is with automatic working mode and pedal switch control mode, which you can choose according to production need.
3.The filling heads have anti-dripping function, ensuring filling accuracy.
4.With high-precision piston, it can fill liquid accurately.
5.Made in desktop design, it can save working space, which is suitable for indivisual workshop.
6.With high-quality check valve, it can effectively prevent the material from flowing backwards, making sure the material can flow smoothly.
Parameter
Filling Range | 10-100ml | 30-300ml | 50-500ml | 100-1000ml | 500-3000ml | 1000-5000ml |
Filling Speed | About 25-40 bottles/min | |||||
Filling Accuracy | ≥±1% | |||||
Air Supply | 0.3-0.4Mpa | 0.4-0.6Mpa | 0.5-0.7Mpa | |||
Packing Size | About 1150*425*715mm | |||||
Machine Size | About 850*625*250mm | |||||
Net Weight/Gross Weight | About 61kg/78kg | |||||
Driven Type | Pneumatic and Electric |
Application
This pneumatic machine can be used for liquid like shampoo, shower gel, juice, beverage, water, vinegar, etc. It can be widely used in medicine, daily chemical, beverage industries. We also have 1/2 heads machines. Please contact us if you need.
